Although the cost of solar panel mount bracket accounts for only a few percent of the total cost of the entire photovoltaic power generation system, the selection is very important. One of the main considerations is weather resistance. During the 25-year life cycle, the solar panel bracket must ensure that the structure is firm and reliable, and can withstand environmental erosion and wind and snow loads. The safety and reliability of the installation should also be considered, and the optimal use effect can be achieved with the minimum installation cost. In addition, whether it can be maintenance-free in the later stage, whether there is a reliable maintenance guarantee, and whether the bracket can be recycled after the end of its life cycle are important factors to be considered. When designing and constructing a photovoltaic power station, the choice of the type of solar panel bracket needs to be comprehensively considered according to local conditions, because after all, various types of brackets have their own advantages and disadvantages.

1. Appearance are different

The U-shapedsolar panel mount bracket is a steel with a cross section like the English letter "U", so there is no curling from the appearance. The C-shaped solar panel mount bracket has a curled edge in appearance, and its production is automatically processed by a C-shaped steel forming machine.

2. Performance are different

The U-shaped solar panel bracket can bears high pressure, supports for a long time, and is easy to install and not deformed. It is a new type of steel with strong characteristic. C-type solar panel bracket can effectively resist shear, anti-slip and impact. Corigy C-type steel is cold-formed by high-strength Al-Mg-Zn coating steel, with thin wall and light weight, excellent section performance and very high strength.

3. Installation methods are different

The U-shaped solar panel bracket is mainly installed and fixed through the web, and its hole position is processed in the early stage. The fixed point can be flexibly determined according to the needs of the on-site construction. The C-type photovoltaic supports are connected by flanges and web bolts, and the hole positions are customized to enhance the firmness of the connection.
